    Taiwan Semiconductor Corporation TSM650N15CS

    Part No.:
    TSM650N15CS
    Manufacturer:
    Taiwan Semiconductor Corporation
    Category:
    FETs, MOSFETs
    Package:
    8-SOIC (0.154", 3.90mm Width)
    Description:
    150V, 9A, SINGLE N-CHANNEL POWER
    Quantity:

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Taiwan Semiconductor Corporation
    Series:
    -
    Package/Case:
    8-SOIC (0.154", 3.90mm Width)
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Active
    FET Type:
    N-Channel
    Technology:
    MOSFET (Metal Oxide)
    Drain to Source Voltage (Vdss):
    150 V
    Current - Continuous Drain (Id) @ 25°C:
    4A (Ta), 9A (Tc)
    Drive Voltage (Max Rds On, Min Rds On):
    6V, 10V
    Rds On (Max) @ Id, Vgs:
    65mOhm @ 4A, 10V
    Vgs(th) (Max) @ Id:
    4V @ 250µA
    Gate Charge (Qg) (Max) @ Vgs:
    37 nC @ 10 V
    Vgs (Max):
    ±20V
    Input Capacitance (Ciss) (Max) @ Vds:
    1783 pF @ 75 V
    FET Feature:
    -
    Power Dissipation (Max):
    2.2W (Ta), 12.5W (Tc)
    Operating Temperature:
    -55°C ~ 150°C (TJ)
    Grade:
    -
    Qualification:
    -
    Mounting Type:
    Surface Mount
    Supplier Device Package:
    8-SOP
