Nexperia USA Inc. PSMN9R5-30YLC,115
- Part No.:
- PSMN9R5-30YLC,115
- Manufacturer:
- Nexperia USA Inc.
- Category:
- FETs, MOSFETs
- Package:
- SC-100, SOT-669
- Datasheet:
-
PSMN9R5-30YLC,115.pdf
- Description:
- MOSFET N-CH 30V 44A LFPAK56
- Quantity:
Product details
- Specifications
- FAQ
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Nexperia USA Inc.
- Series:
- -
- Package/Case:
- SC-100, SOT-669
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- FET Type:
- N-Channel
- Technology:
- MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):
- 30 V
- Current - Continuous Drain (Id) @ 25°C:
- 44A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):
- 4.5V, 10V
- Rds On (Max) @ Id, Vgs:
- 9.8mOhm @ 15A, 10V
- Vgs(th) (Max) @ Id:
- 1.95V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:
- 10.4 nC @ 10 V
- Vgs (Max):
- ±20V
- Input Capacitance (Ciss) (Max) @ Vds:
- 681 pF @ 15 V
- FET Feature:
- -
- Power Dissipation (Max):
- 34W (Tc)
- Operating Temperature:
- -55°C ~ 175°C (TJ)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- LFPAK56, Power-SO8
- Datasheet:
-
PSMN9R5-30YLC,115.pdf
