Toggle Switches
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Length | Illumination | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Panel Cutout Dimensions | Bushing Thread | Ingress Protection | Features | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IL254-63SWITCH TOGGLE 4PDT 15A 125V |
3,833 | 7.79 |
|
- |
I | Bulk | Active | Panel Mount | 4PDT | On-On | 15A (AC) | 125 V | - | Standard Round | - | Non-Illuminated | - | - | Screw Terminal | Circular - 12.70mm Dia | 15/32-32 | - | - | 0°C ~ 85°C |
|
|
5239Y6ADKB2X386TOGGLE SWITCH 5000 MINIATURE |
1,074 | - |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
A227K12KZG-M8SWITCH TOGGLE DPDT 6A 125V |
4,873 | 7.87 |
|
Datasheet |
A | Bulk | Active | Panel Mount | DPDT | Mom-Off-Mom | 6A (AC/DC) | 125 V | 28 V | Locking Lever | 15.47mm | Non-Illuminated | - | - | Solder Lug | - | 1/4-40 | - | Epoxy Sealed Terminals | -30°C ~ 90°C |
|
|
A321P32Y5ZQSWITCH TOGGLE 3PDT 6A 125V |
4,143 | 7.87 |
|
Datasheet |
A | Bulk | Active | Panel Mount | 3PDT | On-Off-On | 6A (AC/DC) | 125 V | 28 V | Flatted | 11.38mm | Non-Illuminated | - | - | Solder Lug | - | 1/4-40 | - | Satin Chrome Actuator | -30°C ~ 90°C |
|
|
101TL2-31SWITCH TOGGLE SPDT 7.5A 115V |
1,097 | - |
|
Datasheet |
TL | Bulk | Obsolete | Panel Mount | SPDT | On-On | 7.5A (AC/DC) | 115 V | 30 V | Standard Round | 17.27mm | Non-Illuminated | - | - | IWTS | Circular - 12.40mm Dia | 15/32-32 | Environment Sealed | - | -65°C ~ 71°C |
|
|
5249WA3VX386TOGGLE SWITCH 5000 MINIATURE |
4,057 | - |
|
Datasheet |
5000 | Bulk | Active | Through Hole, Right Angle, Vertical | DPDT | On-Off-On | 6A (AC), 4A (DC) | 125 V | 30 V | Standard Round | 13.50mm | Non-Illuminated | - | - | PC Pin | - | Unthreaded | - | - | -40°C ~ 85°C |
|
M-597SWITCH TOGGLE SPST-NC 10A 12V |
3,996 | 10.59 |
|
Datasheet |
- | Bulk | Active | Panel Mount | SPST-NC | On-Mom | 10A (DC) | - | 12 V | Standard Round | 17.46mm | Non-Illuminated | - | - | Wire Leads | - | - | - | - | - |
|
|
7415P3HZGISWITCH TOGGLE DP3T 5A 120V |
2,806 | 6.99 |
|
Datasheet |
7000 | Bulk | Active | Panel Mount | DP3T | Mom-On-Mom | 5A (AC/DC) | 120 V | 28 V | Flat Anti-Rotation | 11.43mm | Non-Illuminated | - | - | Solder Lug | Circular - 6.35mm Dia | 1/4-40 | - | Jumper needed to achieve triple throw | -30°C ~ 85°C |
|
|
IL254-NBL8SWITCH TOGGLE 4PDT 15A 125V |
1,046 | 7.80 |
|
- |
I | Bulk | Active | Panel Mount | 4PDT | On-On | 15A (AC) | 125 V | - | Paddle | 17.45mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.70mm Dia | 15/32-32 | - | - | 0°C ~ 85°C |
|
|
1NT1-6FSWITCH TOGGLE SPST-NO 10A 125V |
3,811 | 7.11 |
|
Datasheet |
NT | Bulk | Active | Panel Mount | SPST-NO | Off-Mom | 10A (AC) | 125 V | - | Locking Lever | 26.67mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.40mm Dia | 15/32-32 | IP67/IP68 - Dust Tight, Waterproof | Sealed | -40°C ~ 71°C |
|
MTG72A2SWITCH TOGGLE SPDT 4A 30V |
2,916 | 8.20 |
|
Datasheet |
MT | Bulk | Active | Panel Mount | SPDT | Mom-Off-Mom | 4A (DC) | - | 30 V | Rocker | 11.24mm | - | - | - | Solder Lug | Circular - 17.65mm Dia | 11/16-28 | IP68 - Dust Tight, Waterproof | Black Actuator | -40°C ~ 85°C |
|
|
A435S1YZBSWITCH TOGGLE DP3T 6A 125V |
2,149 | 7.90 |
|
Datasheet |
A | Bulk | Active | Panel Mount | DP3T | Mom-On-Mom | 6A (AC/DC) | 125 V | 28 V | Standard Round | 10.41mm | Non-Illuminated | - | - | Solder Lug | - | 1/4-40 | - | Jumper needed to achieve triple throw | -30°C ~ 90°C |
|
|
HK25S-73SWITCH TOGGLE 3PST-NC 15A 125V |
4,998 | 7.19 |
|
Datasheet |
H | Bulk | Active | Panel Mount | 3PST-NC | On-Mom | 15A (AC) | 125 V | - | Standard Round | 17.45mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.70mm Dia | 15/32-32 | - | - | 0°C ~ 85°C |
|
|
HK25E-73SWITCH TOGGLE 3PST-NO 15A 125V |
1,541 | 7.19 |
|
Datasheet |
H | Bulk | Active | Panel Mount | 3PST-NO | Off-Mom | 15A (AC) | 125 V | - | Standard Round | 17.45mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.70mm Dia | 15/32-32 | - | - | 0°C ~ 85°C |
|
|
MTL406NSWITCH TOGGLE 4PDT 6A 125V |
3,714 | 8.19 |
|
Datasheet |
MTL Green | Bulk | Active | Panel Mount | 4PDT | On-On | 6A (AC), 4A (DC) | 125 V | 28 V | Locking Lever | 17.00mm | Non-Illuminated | - | - | Solder Lug | - | 1/4-40 | - | Epoxy Sealed Terminals | -20°C ~ 80°C |
|
|
1TL11-5SWITCH TOGGLE SPDT 10A 125V |
4,949 | 7.55 |
|
Datasheet |
TL | Bulk | Obsolete | Panel Mount | SPDT | On-Off-Mom | 10A (AC) | 125 V | - | Standard Round | 17.27mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.40mm Dia | 15/32-32 | Environment Sealed | - | -65°C ~ 71°C |
|
AML23EBA2AA05SWITCH TOGGLE SPDT 3A 125V |
4,601 | 7.41 |
|
Datasheet |
AML23 | Bulk | Active | Panel Mount, Snap-In | SPDT | Mom-Off-Mom | 3A (AC), 2A (DC) | 125 V | 24 V | Paddle | - | Non-Illuminated | - | - | Solder, Quick Connect - 0.110" (2.8mm) | Rectangular - 28.98mm x 19.05mm | - | - | - | - |
|
|
AML23EBA2AA01SWITCH TOGGLE SPDT 3A 125V |
3,158 | 7.41 |
|
Datasheet |
AML23 | Bulk | Active | Panel Mount, Snap-In | SPDT | On-On | 3A (AC), 2A (DC) | 125 V | 24 V | Paddle | - | Non-Illuminated | - | - | Solder, Quick Connect - 0.110" (2.8mm) | Rectangular - 28.98mm x 19.05mm | - | - | - | - |
|
|
5236MIWRADB2VTOGGLE SWITCH 5000 MINIATURE |
4,988 | - |
|
Datasheet |
5000 | Bulk | Active | Panel Mount | SPDT | On-On | 6A (AC), 4A (DC) | 125 V | 30 V | Standard Round | 10.50mm | Non-Illuminated | - | - | Wire Wrap | Circular - 6.50mm Dia | 1/4-40 | - | - | -40°C ~ 85°C |
|
|
5664THAB9SWITCH TOGGLE DP3T 6A 125V |
2,469 | 7.39 |
|
Datasheet |
5000 | Bulk | Active | Panel Mount | DP3T | On-On-On | 6A (AC), 4A (DC) | 125 V | 30 V | Flatted | 11.40mm | Non-Illuminated | - | - | Solder Lug | Circular - 6.50mm Dia | - | - | Jumper needed to achieve triple throw | -40°C ~ 85°C |
