Fixed Inductors
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EXL1V0703-2R7-RFIXED IND 2.7UH 11.4A 15.4 MOHM |
1,459 | 0.10 |
|
Datasheet |
EXL1V0703 | Nonstandard | Tape & Reel (TR) | Active | Molded | Iron Powder | 2.7 µH | ±20% | 11.4 A | 13.5A | Shielded | 15.4mOhm Max | - | 23MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.331" L x 0.315" W (8.40mm x 8.00mm) | 0.122" (3.10mm) |
|
ISC1210ER220KFIXED IND 22UH 150MA 3.1 OHM SMD |
1,361 | 0.10 |
|
Datasheet |
ISC-1210 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 22 µH | ±10% | 150 mA | - | Shielded | 3.1Ohm Max | 30 @ 2.52MHz | 16MHz | - | -55°C ~ 125°C | 2.52 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.49mm) | 0.095" (2.41mm) |
|
AMPLH7025S-1R0MTFIXED IND 1UH 13A 6.8MOHM SMD |
1,000 | - |
|
Datasheet |
AMPLH7025S | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 1 µH | ±20% | 15 A | 17A | Shielded | 6.8mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low DCR, Soft Saturation | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.094" (2.40mm) |
|
|
AMPLH7025S-R47MTFIXED IND 0.47UH 16A 4.2MOHM SMD |
1,000 | - |
|
Datasheet |
AMPLH7025S | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 470 nH | ±20% | 19 A | 27A | Shielded | 4.2mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low DCR, Soft Saturation | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.094" (2.40mm) |
|
|
AMPLH7025S-R33MTFIXED IND 0.33UH 18A 2.4MOHM SMD |
1,000 | - |
|
Datasheet |
AMPLH7025S | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 330 nH | ±20% | 21 A | 33A | Shielded | 2.4mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low DCR, Soft Saturation | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.094" (2.40mm) |
|
|
AMPLH7025S-3R3MTFIXED IND 3.3UH 7A 27.6MOHM SMD |
1,000 | - |
|
Datasheet |
AMPLH7025S | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 3.3 µH | ±20% | 8 A | 9A | Shielded | 27.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low DCR, Soft Saturation | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.094" (2.40mm) |
|
|
AMPLH7025S-R68MTFIXED IND 0.68UH 15A 4.6MOHM SMD |
1,000 | - |
|
Datasheet |
AMPLH7025S | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 680 nH | ±20% | 17 A | 23A | Shielded | 4.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low DCR, Soft Saturation | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.094" (2.40mm) |
|
|
DR1030-2R8-RFIXED IND 2.8UH 5.1A 14.5MOHM SM |
990 | 0.10 |
|
Datasheet |
DR1030 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 2.8 µH | ±30% | 5.1 A | 6.08A | Shielded | 14.5mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.413" L x 0.406" W (10.50mm x 10.30mm) | 0.118" (3.00mm) |
|
|
AMPLH7025S-6R8MTFIXED IND 6.8UH 5A 50.6MOHM SMD |
990 | - |
|
Datasheet |
AMPLH7025S | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 6.8 µH | ±20% | 6 A | 7A | Shielded | 50.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low DCR, Soft Saturation | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.094" (2.40mm) |
|
|
AMPLH7025S-100MTFIXED IND 10UH 4.5A 73.6MOHM SMD |
980 | - |
|
Datasheet |
AMPLH7025S | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 10 µH | ±20% | 5 A | 5.5A | Shielded | 73.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low DCR, Soft Saturation | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.094" (2.40mm) |
|
|
AMPLH7025S-4R7MTFIXED IND 4.7UH 6A 36.8MOHM SMD |
975 | - |
|
Datasheet |
AMPLH7025S | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 4.7 µH | ±20% | 7 A | 8A | Shielded | 36.8mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low DCR, Soft Saturation | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.094" (2.40mm) |
|
|
AMPLH7025S-2R2MTFIXED IND 2.2UH 9A 14.7MOHM SMD |
970 | - |
|
Datasheet |
AMPLH7025S | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 2.2 µH | ±20% | 10 A | 12A | Shielded | 14.7mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low DCR, Soft Saturation | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.094" (2.40mm) |
|
AMPLA7050Q-1R0MTFIXED IND 1UH 15A 6.5 MOHM SMD |
750 | 0.18 |
|
Datasheet |
AMPLA7050Q | Nonstandard | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 1 µH | ±20% | 15 A | 20A | Shielded | 6.5mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.197" (5.00mm) |
|
APCI000707462R2M80INDUCTOR POWER |
716 | 0.10 |
|
Datasheet |
APCI | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 2.2 µH | ±20% | 5 A | 6.5A | Shielded | 12.6mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.181" (4.60mm) |
|
|
AMPLA7050Q-6R8MTFIXED IND 6.8UH 5.5A 51.5MOHM SM |
435 | 0.18 |
|
Datasheet |
AMPLA7050Q | Nonstandard | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | 6.8 µH | ±20% | 5.5 A | 8.5A | Shielded | 51.5mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.287" L x 0.260" W (7.30mm x 6.60mm) | 0.197" (5.00mm) |
|
B82442T1683K000FIXED IND 68UH 570MA 781MOHM SMD |
3,000 | 0.12 |
|
Datasheet |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 68 µH | ±10% | 570 mA | 1.05A | Unshielded | 781mOhm Max | 15 @ 2.52MHz | 7MHz | AEC-Q200 | -55°C ~ 150°C | 2.52 MHz | - | Surface Mount | - | 0.220" L x 0.197" W (5.60mm x 5.00mm) | 0.209" (5.30mm) |
|
|
B82442T1394K000FIXED IND 390UH 260MA 3.7OHM SMD |
2,970 | 0.12 |
|
Datasheet |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 390 µH | ±10% | 260 mA | 520mA | Unshielded | 3.7Ohm Max | 20 @ 796kHz | 3MHz | AEC-Q200 | -55°C ~ 150°C | 796 kHz | - | Surface Mount | - | 0.220" L x 0.197" W (5.60mm x 5.00mm) | 0.209" (5.30mm) |
|
|
B82442T1684K000FIXED IND 680UH 210MA 5.87OHM SM |
2,848 | 0.12 |
|
Datasheet |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 680 µH | ±10% | 210 mA | 380mA | Unshielded | 5.87Ohm Max | 20 @ 796kHz | 2.3MHz | AEC-Q200 | -55°C ~ 150°C | 796 kHz | - | Surface Mount | - | 0.220" L x 0.197" W (5.60mm x 5.00mm) | 0.209" (5.30mm) |
|
AMRU000404202R2MB1INDUCTOR POWER |
2,250 | 0.10 |
|
Datasheet |
AMRx | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Metal | 2.2 µH | ±20% | 3 A | 5A | Shielded | 55mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.185" L x 0.165" W (4.70mm x 4.20mm) | 0.079" (2.00mm) |
|
|
B82442T1335K000FIXED IND 3.3MH 85MA 32.8OHM SMD |
1,884 | 0.12 |
|
Datasheet |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 3.3 mH | ±10% | 85 mA | 175mA | Unshielded | 32.8Ohm Max | 30 @ 252kHz | 1MHz | AEC-Q200 | -55°C ~ 150°C | 252 kHz | - | Surface Mount | - | 0.220" L x 0.197" W (5.60mm x 5.00mm) | 0.209" (5.30mm) |
