    Pulse Electronics PE-68422NL

    Part No.:
    PE-68422NL
    Manufacturer:
    Pulse Electronics
    Category:
    Switching Converter, SMPS Transformers
    Package:
    Datasheet:
    HONG KONG HAOCHIP TRADING CO., LIMITEDPE-68422NL.pdf
    Description:
    XFMR FLYBACK DC/DC CONV SMD
    Quantity:

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Pulse Electronics
    Series:
    -
    Packaging:
    Tray
    Product Status:
    Active
    Type:
    For DC/DC Converters
    Applications:
    Flyback Converters
    Intended Chipset:
    LM2585, LM2586, LM2587, LM2588
    Chipset Manufacturer:
    National Semiconductor
    Voltage - Primary:
    18 ~ 36V
    Voltage - Auxiliary:
    -
    Voltage - Isolation:
    1500Vrms
    Inductance @ Frequency:
    -
    Frequency:
    -
    Operating Temperature:
    -40°C ~ 130°C
    Grade:
    -
    Qualification:
    -
    Mounting Type:
    Surface Mount
    Size / Dimension:
    0.970" L x 1.070" W (24.64mm x 27.18mm)
    Height - Seated (Max):
    0.680" (17.27mm)
    Footprint:
    0.970" L x 1.070" W (24.64mm x 27.18mm)
    Style:
    -
