    Panasonic Electric Works HE1AN-W-DC24V-Y7

    Part No.:
    HE1AN-W-DC24V-Y7
    Manufacturer:
    Panasonic Electric Works
    Category:
    Power Relays, Over 2 Amps
    Package:
    Datasheet:
    HONG KONG HAOCHIP TRADING CO., LIMITEDHE1AN-W-DC24V-Y7.pdf
    Description:
    RELAY GEN PURPOSE SPST 120A 24V
    Quantity:

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Panasonic Electric Works
    Series:
    HE-N
    Packaging:
    Tray
    Product Status:
    Active
    Mounting Type:
    Through Hole
    Coil Voltage:
    24VDC
    Contact Form:
    SPST-NO (1 Form A)
    Contact Rating (Current):
    120 A
    Switching Voltage:
    800VAC, 60VDC - Max
    Load - Max Switching:
    96000VA, 7200W
    Coil Current:
    104 mA
    Coil Type:
    Non Latching
    Features:
    -
    Termination Style:
    PC Pin
    Seal Rating:
    Sealed - Flux Protection
    Coil Insulation:
    Class F
    Must Operate Voltage:
    18 VDC
    Must Release Voltage:
    1.2 VDC
    Operate Time:
    30 ms
    Release Time:
    10 ms
    Operating Temperature:
    -40°C ~ 55°C
    Contact Material:
    Silver Nickel (AgNi)
    Relay Type:
    General Purpose
    Grade:
    -
    Qualification:
    -
    Datasheet:
    HONG KONG HAOCHIP TRADING CO., LIMITEDHE1AN-W-DC24V-Y7.pdf
