    onsemi FGA40T65SHD

    Part No.:
    FGA40T65SHD
    Manufacturer:
    onsemi
    Category:
    Single IGBTs
    Package:
    TO-3P-3, SC-65-3
    Datasheet:
    HONG KONG HAOCHIP TRADING CO., LIMITEDFGA40T65SHD.pdf
    Description:
    IGBT TRENCH FS 650V 80A TO3PN
    Quantity:

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    onsemi
    Series:
    -
    Package/Case:
    TO-3P-3, SC-65-3
    Packaging:
    Tube
    Product Status:
    Active
    IGBT Type:
    Trench Field Stop
    Voltage - Collector Emitter Breakdown (Max):
    650 V
    Current - Collector (Ic) (Max):
    80 A
    Current - Collector Pulsed (Icm):
    120 A
    Vce(on) (Max) @ Vge, Ic:
    2.1V @ 15V, 40A
    Power - Max:
    268 W
    Switching Energy:
    1.01mJ (on), 297µJ (off)
    Input Type:
    Standard
    Gate Charge:
    72.2 nC
    Td (on/off) @ 25°C:
    19.2ns/65.6ns
    Test Condition:
    400V, 40A, 6Ohm, 15V
    Reverse Recovery Time (trr):
    31.8 ns
    Operating Temperature:
    -55°C ~ 175°C (TJ)
    Grade:
    -
    Qualification:
    -
    Mounting Type:
    Through Hole
    Supplier Device Package:
    TO-3PN
    Datasheet:
    HONG KONG HAOCHIP TRADING CO., LIMITEDFGA40T65SHD.pdf

    1. How to order FGA40T65SHD on HONG KONG HAOCHIP TRADING CO., LIMITED?

    Currently, HONG KONG HAOCHIP TRADING CO., LIMITED only provide peer-to-peer order processing. While you submit the RFQ, our professional agent will contact you with the competitive prices in the global market, and our agent will prompt you to finish the order if you accept our offers.

    2. How does HONG KONG HAOCHIP TRADING CO., LIMITED guarantee that FGA40T65SHD is from the original manufacturer or authorized agents?

    We have a professional and experienced quality control team to strictly verify and test the FGA40T65SHD. All suppliers must pass our qualification reviews before they can publish their products including FGA40T65SHD on HONG KONG HAOCHIP TRADING CO., LIMITED; we pay more attention to the channels and quality of FGA40T65SHD products than any other customer. We strictly implement supplier audits, so you can purchase with confidence.

    3. Are the FGA40T65SHD price and inventory displayed accurate?

    The price and inventory of FGA40T65SHD fluctuates frequently and cannot be updated in time, it will be updated periodically within 24 hours. And, our quotation usually expires after 5 days.

    4. What forms of payment are accepted?

    Wire Transfer, PayPal, Alipay, Wechat, Credit Card, Western Union, MoneyGram, and Escrow are all acceptable.

    Warm Tips: Some orders in certain payment forms may require handling fee.

    5. How is the shipping arranged?

    Customers can choose industry-leading freight companies, including DHL, UPS, FedEx, TNT, and Registered Mail. Shipping insurance is also available.

    Once your order has been processed for shipment, our salesperson will send you an email advising you of the shipping status and tracking number.

    Warm Tips: It may take up to 24 hours for the carriers to display tracking information. Usually, express delivery takes 3-5 days, and registered mail takes 25-60 days.

    6. What is the process for return or replacement of FGA40T65SHD?

    All goods will implement Pre-Shipment Inspection (PSI), selected at random from all batches of your order to do a systematic inspection before arranging the shipment. If there is something wrong with the FGA40T65SHD we delivered, we will accept the replacement or return of the FGA40T65SHD only when all of the below conditions are fulfilled:

    (1)Such as a deficiency in quantity, delivery of wrong items, and apparent external defects (breakage and rust, etc.), and we acknowledge such problems.

    (2)We are informed of the defect described above within 90 days after the delivery of FGA40T65SHD.

    (3)The PartNo is unused and only in the original unpacked packaging.

    Two processes to return the products:

    (1)Inform us within 90 days

    (2)Obtain Requesting Return Authorizations

    7.How to contact us to get technical supports, such as FGA40T65SHD pin diagram, FGA40T65SHD datasheet?

    If you need any after-sales service, please do not hesitate to contact us.

    Image FGA40T65SHD FGA40T65SHDF
    Part Number FGA40T65SHD FGA40T65SHDF
    Manufacturer onsemi onsemi
    Series - -
    Package/Case TO-3P-3, SC-65-3 TO-3P-3, SC-65-3
    Packaging Tube Tube
    Product Status Active Obsolete
    IGBT Type Trench Field Stop Trench Field Stop
    Voltage - Collector Emitter Breakdown (Max) 650 V 650 V
    Current - Collector (Ic) (Max) 80 A 80 A
    Current - Collector Pulsed (Icm) 120 A 120 A
    Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 40A 1.81V @ 15V, 40A
    Power - Max 268 W 268 W
    Switching Energy 1.01mJ (on), 297µJ (off) 1.22mJ (on), 440µJ (off)
    Input Type Standard Standard
    Gate Charge 72.2 nC 68 nC
    Td (on/off) @ 25°C 19.2ns/65.6ns 18ns/64ns
    Test Condition 400V, 40A, 6Ohm, 15V 400V, 40A, 6Ohm, 15V
    Reverse Recovery Time (trr) 31.8 ns 101 ns
    Operating Temperature -55°C ~ 175°C (TJ) -55°C ~ 175°C (TJ)
    Grade - -
    Qualification - -
    Mounting Type Through Hole Through Hole
    Supplier Device Package TO-3PN TO-3PN
