onsemi FDD8424H-F085A
- Part No.:
- FDD8424H-F085A
- Manufacturer:
- onsemi
- Category:
- FET, MOSFET Arrays
- Package:
- TO-252-5, DPAK (4 Leads + Tab), TO-252AD
- Datasheet:
-
FDD8424H-F085A.pdf
- Description:
- MOSFET N/P-CH 40V 9A/6.5A TO252
- Quantity:
Product details
- Specifications
- FAQ
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- onsemi
- Series:
- PowerTrench®
- Package/Case:
- TO-252-5, DPAK (4 Leads + Tab), TO-252AD
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Obsolete
- Technology:
- MOSFET (Metal Oxide)
- Configuration:
- N and P-Channel
- FET Feature:
- Logic Level Gate
- Drain to Source Voltage (Vdss):
- 40V
- Current - Continuous Drain (Id) @ 25°C:
- 9A, 6.5A
- Rds On (Max) @ Id, Vgs:
- 24mOhm @ 9A, 10V
- Vgs(th) (Max) @ Id:
- 3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:
- 20nC @ 10V
- Input Capacitance (Ciss) (Max) @ Vds:
- 1000pF @ 20V
- Power - Max:
- 1.3W
- Operating Temperature:
- -55°C ~ 150°C (TJ)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- TO-252 (DPAK)
- Datasheet:
-
FDD8424H-F085A.pdf
