    Eaton - Electronics Division CTX100-5-R

    Part No.:
    CTX100-5-R
    Manufacturer:
    Eaton - Electronics Division
    Category:
    Arrays, Signal Transformers
    Package:
    Nonstandard SMD
    Datasheet:
    HONG KONG HAOCHIP TRADING CO., LIMITEDCTX100-5-R.pdf
    Description:
    INDUCT ARRAY 4 COIL SMD
    Quantity:

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Eaton - Electronics Division
    Series:
    OCTA-PAC®
    Package/Case:
    Nonstandard SMD
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Obsolete
    Number of Coils:
    4
    Inductance - Connected In Parallel:
    -
    Inductance - Connected In Series:
    -
    Tolerance:
    -
    Current Rating - Parallel:
    -
    Current Rating - Series:
    -
    Current Saturation - Parallel:
    -
    Current Saturation - Series:
    -
    DC Resistance (DCR) - Parallel:
    -
    DC Resistance (DCR) - Series:
    -
    Shielding:
    Unshielded
    Ratings:
    -
    Operating Temperature:
    -40°C ~ 85°C
    Mounting Type:
    Surface Mount
    Size / Dimension:
    0.670" L x 0.670" W (17.02mm x 17.02mm)
    Height:
    0.325" (8.26mm)
    Datasheet:
    HONG KONG HAOCHIP TRADING CO., LIMITEDCTX100-5-R.pdf
