Rotary Switches
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Number of Positions | Index Stops | Number of Decks | Number of Poles per Deck | Circuit per Deck | Contact Timing | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Length | Angle of Throw | Contact Material | Contact Finish | Mounting Type | Termination Style | Features | Depth Behind Panel |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
212-3T3ESWITCH ROTARY 3POS 20A 150V |
1,491 | 89.29 |
|
Datasheet |
212 | Box | Active | 3 | Fixed | 3 | 1 | SP3T | Non-Shorting (BBM) | 20A (AC/DC) | 150 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 157.16mm |
|
312-12T2ESWITCH ROTARY 12POS 30A 300V |
2,833 | 88.75 |
|
Datasheet |
312 | Bulk | Active | 12 | Fixed | 2 | 1 | SP12T | Non-Shorting (BBM) | 30A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 117.50mm |
|
|
212-4T3ESWITCH ROTARY 4POS 20A 150V |
4,693 | 90.72 |
|
Datasheet |
212 | Bulk | Active | 4 | Fixed | 3 | 1 | SP4T | Non-Shorting (BBM) | 20A (AC/DC) | 150 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 157.20mm |
|
|
412-8T2ESWITCH ROTARY 8POS 50A 300V |
1,967 | 93.13 |
|
Datasheet |
412 | Bulk | Active | 8 | Fixed | 2 | 1 | SP8T | Non-Shorting (BBM) | 50A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 127.80mm |
|
|
212-5T3ESWITCH ROTARY 5POS 20A 150V |
2,755 | 93.49 |
|
Datasheet |
212 | Bulk | Active | 5 | Fixed | 3 | 1 | SP5T | Non-Shorting (BBM) | 20A (AC/DC) | 150 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 157.20mm |
|
N80 E WU3+G2SWITCH ROTARY 3POS 80A |
1,685 | 99.43 |
|
Datasheet |
N80 | Retail Package | Active | 3 | - | - | - | - | - | 80A | - | - | - | - | - | - | - | Panel Mount | Screw Terminal | - | - |
|
|
59M18-07-1-09NSWITCH ROTARY 9POS 250MA 115V |
2,875 | 85.92 |
|
Datasheet |
59 | Bulk | Active | 9 | Fixed | 7 | 1 | SP9T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 18° | Silver Alloy | Gold | Panel Mount | Solder Lug | - | 80.37mm |
|
|
212-6T3ESWITCH ROTARY 6POS 20A 150V |
1,109 | 96.25 |
|
Datasheet |
212 | Bulk | Active | 6 | Fixed | 3 | 1 | SP6T | Non-Shorting (BBM) | 20A (AC/DC) | 150 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 157.20mm |
|
|
412-9T2ESWITCH ROTARY 9POS 50A 300V |
3,921 | 96.43 |
|
Datasheet |
412 | Bulk | Active | 9 | Fixed | 2 | 1 | SP9T | Non-Shorting (BBM) | 50A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 127.80mm |
|
|
212-7T3ESWITCH ROTARY 7POS 20A 150V |
3,281 | 98.47 |
|
Datasheet |
212 | Bulk | Active | 7 | Fixed | 3 | 1 | SP7T | Non-Shorting (BBM) | 20A (AC/DC) | 150 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 157.20mm |
|
|
412-10T2SWITCH ROTARY 10POS 50A 300V |
3,640 | 110.48 |
|
Datasheet |
412 | Bulk | Active | 10 | Fixed | 2 | 1 | SP10T | Non-Shorting (BBM) | 50A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 127.80mm |
|
|
59HS18-07-2-10SSWITCH ROTARY 10POS 250MA 115V |
3,358 | 95.17 |
|
Datasheet |
59 | Bulk | Active | 10 | Fixed | 7 | 2 | DP10T | Shorting (MBB) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 18° | Silver Alloy | Gold | Panel Mount | Solder Lug | Shaft and Panel Sealed | 80.37mm |
|
|
59HS18-07-1-18NSWITCH ROTARY 18POS 250MA 115V |
4,870 | 90.91 |
|
Datasheet |
59 | Bulk | Active | 18 | Fixed | 7 | 1 | SP18T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 18° | Silver Alloy | Gold | Panel Mount | Solder Lug | Shaft and Panel Sealed | 80.37mm |
|
|
212-8T3ESWITCH ROTARY 8POS 20A 150V |
1,275 | 102.35 |
|
Datasheet |
212 | Bulk | Active | 8 | Fixed | 3 | 1 | SP8T | Non-Shorting (BBM) | 20A (AC/DC) | 150 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 157.20mm |
|
|
412-10T2ESWITCH ROTARY 10POS 50A 300V |
2,769 | 101.36 |
|
Datasheet |
412 | Bulk | Active | 10 | Fixed | 2 | 1 | SP10T | Non-Shorting (BBM) | 50A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 127.80mm |
|
|
59M18-07-2-10SSWITCH ROTARY 10POS 250MA 115V |
1,018 | - |
|
Datasheet |
59 | Bulk | Active | 10 | Fixed | 7 | 2 | DP10T | Shorting (MBB) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 18° | Silver Alloy | Gold | Panel Mount | Solder Lug | - | 80.37mm |
|
|
E4C0417SSWITCH ROTARY 2-17POS 9A 115V |
3,784 | 116.98 |
|
Datasheet |
E4 | Bulk | Active | 2 ~ 17 | Adjustable | 4 | 1 | SP17T | Shorting (MBB) | 9A (AC), 11A (DC) | 115 V | 28 V | Flatted (6.35mm Dia) | 47.63mm | 20° | Silver (Ag) | - | Panel Mount | Solder Lug | - | 116.79mm |
|
|
212-9T3ESWITCH ROTARY 9POS 20A 150V |
2,866 | 104.00 |
|
Datasheet |
212 | Bulk | Active | 9 | Fixed | 3 | 1 | SP9T | Non-Shorting (BBM) | 20A (AC/DC) | 150 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 157.20mm |
|
|
412-12T2SWITCH ROTARY 12POS 50A 300V |
1,978 | 117.65 |
|
Datasheet |
412 | Bulk | Active | 12 | Fixed | 2 | 1 | SP12T | Non-Shorting (BBM) | 50A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 127.80mm |
|
|
312-4T3SWITCH ROTARY 4POS 30A 300V |
4,295 | 118.23 |
|
Datasheet |
312 | Bulk | Active | 4 | Fixed | 3 | 1 | SP4T | Non-Shorting (BBM) | 30A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 177.80mm |
