FETs, MOSFETs
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PHK04P02T,518MOSFET P-CH 16V 4.66A 8SO Nexperia USA Inc. |
5,045 | - |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Obsolete | P-Channel | MOSFET (Metal Oxide) | 16 V | 4.66A (Tc) | 2.5V, 10V | 120mOhm @ 1A, 4.5V | 600mV @ 1mA (Typ) | 7.2 nC @ 4.5 V | ±8V | 528 pF @ 12.8 V | - | 5W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SO |
|
PH955L,115MOSFET N-CH 55V 62.5A LFPAK56 Nexperia USA Inc. |
8,969 | 0.20 |
|
Datasheet |
TrenchMOS™ | SC-100, SOT-669 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 55 V | 62.5A (Tc) | 4.5V, 10V | 8.3mOhm @ 25A, 10V | 2V @ 1mA | 42 nC @ 5 V | ±20V | 2836 pF @ 25 V | - | 62.5W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | LFPAK56, Power-SO8 |
|
|
PHK13N03LT,518MOSFET N-CH 30V 13.8A 8SO Nexperia USA Inc. |
8,447 | - |
|
Datasheet |
TrenchMOS™ | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 13.8A (Tc) | 4.5V, 10V | 20mOhm @ 8A, 10V | 2V @ 250µA | 10.7 nC @ 5 V | ±20V | 752 pF @ 15 V | - | 6.25W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SO |
|
PSMN003-30P,127MOSFET N-CH 30V 75A TO220AB Nexperia USA Inc. |
7,126 | - |
|
Datasheet |
TrenchMOS™ | TO-220-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 75A (Tc) | 5V, 10V | 2.8mOhm @ 25A, 10V | 3V @ 1mA | 170 nC @ 10 V | ±20V | 9200 pF @ 25 V | - | 230W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220AB |
|
|
PSMN006-20K,518MOSFET N-CH 20V 32A 8SO Nexperia USA Inc. |
5,866 | - |
|
Datasheet |
TrenchMOS™ | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 32A (Tc) | 1.8V, 4.5V | 5mOhm @ 5A, 4.5V | 700mV @ 1mA (Typ) | 32 nC @ 2.5 V | ±10V | 4350 pF @ 20 V | - | 8.3W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SO |
|
PSMN008-75B,118MOSFET N-CH 75V 75A D2PAK Nexperia USA Inc. |
5,951 | 0.42 |
|
Datasheet |
TrenchMOS™ | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 75 V | 75A (Tc) | 10V | 8.5mOhm @ 25A, 10V | 4V @ 1mA | 122.8 nC @ 10 V | ±20V | 5260 pF @ 25 V | - | 230W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | D2PAK |
|
BSN20,235MOSFET N-CH 50V 173MA TO236AB Nexperia USA Inc. |
3,655 | - |
|
Datasheet |
TrenchMOS™ | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 50 V | 173mA (Ta) | 5V, 10V | 15Ohm @ 100mA, 10V | 1V @ 1mA | - | ±20V | 25 pF @ 10 V | - | 830mW (Tc) | -65°C ~ 150°C (TJ) | - | - | Surface Mount | TO-236AB |
|
PH2525L,115MOSFET N-CH 25V 100A LFPAK56 Nexperia USA Inc. |
2,958 | 0.04 |
|
Datasheet |
TrenchMOS™ | SC-100, SOT-669 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 25 V | 100A (Tc) | 4.5V, 10V | 2.5mOhm @ 25A, 10V | 2.15V @ 1mA | 34.7 nC @ 4.5 V | ±20V | 4470 pF @ 12 V | - | 62.5W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | LFPAK56, Power-SO8 |
|
PML340SN,118MOSFET N-CH 220V 7.3A DFN3333-8 Nexperia USA Inc. |
6,251 | 0.04 |
|
Datasheet |
TrenchMOS™ | 8-VDFN Exposed Pad | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 220 V | 7.3A (Tc) | 6V, 10V | 386mOhm @ 2.6A, 10V | 4V @ 1mA | 13.2 nC @ 10 V | ±20V | 656 pF @ 30 V | - | 50W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DFN3333-8 |
|
|
PHK18NQ03LT,518MOSFET N-CH 30V 20.3A 8SO Nexperia USA Inc. |
3,482 | 0.20 |
|
Datasheet |
TrenchMOS™ | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 20.3A (Tc) | 4.5V, 10V | 8.9mOhm @ 25A, 10V | 2.15V @ 1mA | 10.6 nC @ 4.5 V | ±20V | 1380 pF @ 12 V | - | 6.25W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SO |
