DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
9SG5724H562FAN AXIAL 172X51MM 24VDC WIRE Sanyo Denki America Inc. |
4,111 | - |
|
Datasheet |
San Ace 172 | Box | Active | 24VDC | Rectangular/Rounded - 172mm L x 150mm H | 51.00mm | 410.0 CFM (11.48m³/min) | 2.160 in H2O (540.0 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 71.0dB(A) | 67.2 W | 6500 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.882 lb (400.07 g) |
|
|
109E1748P5K03FAN AXIAL 172X51MM 48VDC WIRE Sanyo Denki America Inc. |
3,231 | - |
|
Datasheet |
San Ace 172 | Box | Active | 48VDC | Round - 172mm Dia | 51.00mm | 300.0 CFM (8.40m³/min) | 0.976 in H2O (243.0 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 55.0dB(A) | 33.6 W | 4100 RPM | 4 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 1.7 lbs (780.0 g) |
|
9EC2048P0A01FAN AXIAL 200X70MM 48VDC WIRE Sanyo Denki America Inc. |
2,819 | - |
|
Datasheet |
San Ace 200 | Box | Active | 48VDC | Round - 200mm Dia | 70.00mm | 519.0 CFM (14.53m³/min) | 2.570 in H2O (640.1 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 68.0dB(A) | 105.6 W | 4800 RPM | 4 Wire Leads | - | -4 ~ 140°F (-20 ~ 60°C) | CSA, TUV, UL | 3.9 lbs (1.8 kg) |
|
|
9EC2048P0J01FAN AXIAL 200X70MM 48VDC WIRE Sanyo Denki America Inc. |
3,406 | - |
|
- |
San Ace 200 | Box | Obsolete | 48VDC | Round - 200mm Dia | 70.00mm | 646.0 CFM (18.09m³/min) | 4.016 in H2O (1000.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 81.0dB(A) | 221.2 W | 6100 RPM | 4 Wire Leads | - | -4 ~ 140°F (-20 ~ 60°C) | CSA, TUV, UL | 3.9 lbs (1.8 kg) |
|
|
9EH1724P5C01FAN AXIAL 172X51MM 24VDC WIRE Sanyo Denki America Inc. |
3,570 | - |
|
Datasheet |
San Ace 172 | Box | Active | 24VDC | Round - 172mm Dia | 51.00mm | - | - | Ball | Tubeaxial | PWM Control, Speed Sensor (Tach) | 60.0dB(A) | 55.2 W | - | 4 Wire Leads | - | - | - | 1.7 lbs (780.0 g) |
|
|
109L1412H102FAN AXIAL 140X38MM 12VDC WIRE Sanyo Denki America Inc. |
2,634 | - |
|
Datasheet |
San Ace 140L | Box | Obsolete | 12VDC | Square - 140mm L x 140mm H | 38.00mm | 159.0 CFM (4.45m³/min) | 0.394 in H2O (98.1 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 46.0dB(A) | 8.76 W | 2600 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 1.3 lbs (600.0 g) |
|
|
109L1412M102FAN AXIAL 140X38MM 12VDC WIRE Sanyo Denki America Inc. |
1,460 | - |
|
Datasheet |
San Ace 140L | Box | Obsolete | 12VDC | Square - 140mm L x 140mm H | 38.00mm | 117.0 CFM (3.28m³/min) | 0.209 in H2O (52.1 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 38.0dB(A) | 3.6 W | 1900 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 1.3 lbs (600.0 g) |
|
|
109L1424M102FAN AXIAL 140X38MM 24VDC WIRE Sanyo Denki America Inc. |
2,397 | - |
|
Datasheet |
San Ace 140L | Box | Obsolete | 24VDC | Square - 140mm L x 140mm H | 38.00mm | 117.0 CFM (3.28m³/min) | 0.209 in H2O (52.1 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 38.0dB(A) | 3.84 W | 1900 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 1.3 lbs (600.0 g) |
|
|
109L1448H102FAN AXIAL 140X38MM 48VDC WIRE Sanyo Denki America Inc. |
2,609 | - |
|
Datasheet |
San Ace 140L | Box | Obsolete | 48VDC | Square - 140mm L x 140mm H | 38.00mm | 159.0 CFM (4.45m³/min) | 0.394 in H2O (98.1 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 46.0dB(A) | 9.6 W | 2600 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 1.3 lbs (600.0 g) |
|
|
109L1448M102FAN AXIAL 140X38MM 48VDC WIRE Sanyo Denki America Inc. |
4,851 | - |
|
Datasheet |
San Ace 140L | Box | Obsolete | 48VDC | Square - 140mm L x 140mm H | 38.00mm | 117.0 CFM (3.28m³/min) | 0.209 in H2O (52.1 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 38.0dB(A) | 4.32 W | 1900 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 1.3 lbs (600.0 g) |
